The Canon imageFORMULA R40II is an ultra-compact desktop scanner designed for space-constrained workspaces and home office. It features a foldable paper tray, scanning speeds of up to 45 ppm (simplex) and 90 ipm (duplex), and advanced image processing for high quality output. With a quick installer setup and guided scanning, it's perfect for beginners and everyday office use.
โปรโมชั่น
คุณสมบัติเด่น
คุณสมบัติ
Ultra-compact, Space-saving
With an ultra-narrow width of just 283 mm, the imageFORMULA R40II is one of the most compact in its class and offers the added advantage of a foldable paper feed tray for easy, space-saving storage.
Easy Setup and Operation
The imageFORMULA R40II is designed for a seamless user experience. Users can easily install the software by following a guided video, which also introduces the scanner’s key features during setup. The scanner features intuitive physical buttons designed for easy operation, while error notifications are clearly displayed via icons on the control panel (monochrome LCD).
Improved Image Processing: Colour Enhancement
The scanner now features an advanced colour enhancement function that makes pale or faint text easier to read, ensuring documents marked with multiple colours are scanned clearly without needing to adjust settings for each page. This function maintains text visibility on multi-coloured documents, eliminates the need to change colour settings for every scan, and processes data efficiently while keeping the same scanning speed as colour mode.
ข้อมูลจำเพาะ
Scan
| Type | Desktop Sheet-Fed Scanner |
| Scanning Speed*1 | |
| Greyscale | 200 dpi: 45 ppm (Simplex) / 90 ipm (Duplex) 300 dpi: 45 ppm (Simplex) / 90 ipm (Duplex) |
| Colour | 200 dpi: 45 ppm (Simplex) / 90 ipm (Duplex) 300 dpi: 40 ppm (Simplex) / 80 ipm (Duplex) |
| Scanning Element | Contact Image Sensor (CIS) |
| Light Source | LED |
| Scanning Side | Simplex / Duplex |
| Scanning Modes | Black and White, Error Diffusion, Greyscale, Advanced Text Enhancement, Advanced Text Enhancement II, Active Threshold, Colour |
| Scanner Features | Folio Scan, Ultrasonic Double Feed Detection |
| Output Resolution*2 | 100/150/200/240/300/400/600/1200 dpi |
Media Handling
| Document Size | |
| Plain Paper | Width: 50 to 216 mm Length: 54 to 356 mm (Up to 6,096 mm long with Long Document mode) |
| Business Card |
Width: 50 to 55 mm
Length: 85 to 91 mm |
| Card (ISO Standard) | 54 x 86 mm |
| Document Thickness and Weight | |
| Plain Paper | 27 to 413 g/m² (0.04 to 0.49 mm) |
| Business Card | 128 to 255 g/m² (Vertical feeding only) |
| Card | 1.4 mm or smaller (Horizontal feeding only) |
| Auto Document Feeder (ADF) Capacity*3 | 60 sheets |
Connectivity & Software
| Interface | USB 3.2 / USB 3.1 / USB 3.0 / USB 2.0 (Connector Type: Type-C) |
| Software | CaptureOnTouch |
General
| Power Requirements | AC 100 - 240 V (50 / 60 Hz) |
| Power Consumption | |
| Scanning (Max.) | 15.6 W or less
|
| Sleep Mode | 0.6 W |
| With Power Switched OFF (Max.) | 0.1 W or less
|
| Operating Environment | |
| Temperature | 10 to 35°C |
| Humidity | 20 to 80% RH |
| Dimensions (W x D x H) | |
| When Trays Are Closed | 283 x 158 x 158 mm
|
| When Trays Are Opened | 283 x 583 x 344 mm
|
| Weight (Approx.) | Approx 3.2 kg (Without AC adapter)
|
Consumables & Accessories
| Options/Consumables | Carrier Sheet (A4), Carrier Sheet (Legal), Replacement Roller, Replacement Roller for Refill |
- Based on A4 portrait document size.
- Primary scan lines x secondary scan lines.
- Size: A4 or smaller, paper weight: 80 g/m².
